Introduction🔗️

So somewhat recently in the Bittide project, we added two very useful libraries: clash-protocols-memmap and clash-bitpackc. clash-protocols-memmap provides a way to build memory mapped peripherals for embedded systems that gives you a register mapping “for free” (with some opt-in cost). Combined with a code generator, you can simply write a component using this library and get a Rust crate or C library that will handle the raw register operations that talk to your peripheral. This library is built on top of clash-bitpackc, which introduces typeclasses that ask you to tell Clash how to pack your Haskell types into C ABI-compatible registers.

The problem🔗️

Generally, when you use clash-protocols-memmap and clash-bitpackc, the goal is that they should be as transparent as possible to the user. That is to say, when they’re writing code to interact with a memory mapped component, the types they work with should look as close as possible to the ones they dealt with when creating the component.

So then, what if you want to have a register for a BitVector n, Unsigned n, Signed n, or Index n? Currently, clash-bitpackc and clash-protocols-memmap do some up-front monomorphization: a BitVector 3 becomes a [u8; 1] in Rust (or a uint8_t* in C), an Unsigned 18 becomes a u32, and so on. While it’s true that these are the correct representations of these types, I found it unsatisfactory that writing a component with an Index 107 in Clash would then require the user to talk about a u8 in Rust. As such, I started work on the clash-num repository.

Limits🔗️

The n in each of the Clash types is of kind Natural, which is an arbitrary precision number. Unfortunately, Rust doesn’t have a primitive type with support for arbitrary precision, and const generics (without an experimental nightly feature) are limited to a subset of primitive types: bool, char, u8, u16, u32, u64, u128, usize, i8, i16, i32, i64, i128, and isize. Keeping this in mind, then, let’s choose types for const generic of each of our Clash types:

  • Index n => Index<const N: u128>
  • Unsigned n => Unsigned<const N: u8>
  • Signed n => Signed<const N: u8>
  • BitVector n => BitVec<const N: usize>

Why u8 on Signed and Unsigned?🔗️

“Doesn’t that limit you to only 256 bit numbers?” you might be asking. And yes, it does! But here’s the thing: if you want to go bigger than even just 128 bits, then you’ll need a backing type that isn’t a numeric primitive. And if you want that, then you must do one of:

  1. Create a custom type to represent numbers with more than 128 bits and implement all the operator types you need on it, e.g. SignedBigNum<N> and UnsignedBigNum<N>, which would then implement Add, Sub, Mul, Div, etc. These would then be used as the backing types for Signed<N> and Unsigned<N> respectively for N > 128.
  2. Create wrapper traits for each of the operators you want Signed<N> and Unsigned<N> to have - and yes, separate ones for each of those too. So you’ll need SignedAdd, UnsignedAdd, SignedSub, UnsignedSub, and so on, which should then be implemented on each of the backing types. Then you can create implementations of the actual language operators on Signed and Unsigned by introducing bounds that look like where BackingType: WrapperTrait.
  3. Realise that >128 bit numbers are kind of a silly idea because:
    1. They’re going to introduce a lot of additional complexity to the crate that I was hoping to avoid
    2. Don’t. Don’t make an Unsigned 256 or Signed 1024 or other such abominations. Stop it. I’m going to take away your keyboard.

So: no “arbitrary”-sized Signed and Unsigned.

Turning const generics into type representations🔗️

So as stated before, we want to have an Index<const N: u128>. To make this happen, we need two things:

  1. A trait that provides an associated type, which will be used as the type representation
  2. Implementations of that trait over relevant ranges of N

With these things, our type definition for Index can look like this:

// Given some `GetIndexRepr<N>`, a type alias that accesses an associated type that provides the
// appropriate type representation for a given size `N`.
pub struct Index<const N: u8>(pub(crate) GetIndexRepr<N>);

Now as for the trait that provides the associated type and its impls, there’s two methods to do this that I know of.

Method 1: Specialization🔗️

I believe that this is the easier to understand way to map a const generic to a type. For this method we will need two things: a marker type with a const bool parameter, and a marker type with a const u8 parameter which we will create specialized impls on to provide the backing type.

#![feature(generic_const_exprs, specialization)]
#![allow(incomplete_features)]

pub const ConstCheck<const B: bool>;
pub trait True {}
impl True for ConstCheck<true> {}
pub trait False {}
impl False for ConstCheck<false> {}

pub struct IndexMarker<const N: u128>;

pub trait IndexRepr {
    type Repr;

    fn bounds_check(val: &Self::Repr) -> bool;
}

// Base impl
impl<const N: u128> IndexRepr for IndexMarker<N> {
    default type Repr = u128;
    // ...
}

// Introduce one additional constraint each time for successive `impl`s:
impl<const N: u128> IndexRepr for IndexMarker<N>
where
    ConstCheck<{ N <= u64::MAX as u128 + 1 }>: True,
{
    default type Repr = u64;
    // ...
}

impl<const N: u128> IndexRepr for IndexMarker<N>
where
    ConstCheck<{ N <= u64::MAX as u128 + 1 }>: True,
    ConstCheck<{ N <= u32::MAX as u128 + 1 }>: True,
{
    default type Repr = u32;
    // ...
}

impl<const N: u128> IndexRepr for IndexMarker<N>
where
    ConstCheck<{ N <= u64::MAX as u128 + 1 }>: True,
    ConstCheck<{ N <= u32::MAX as u128 + 1 }>: True,
    ConstCheck<{ N <= u16::MAX as u128 + 1 }>: True,
{
    default type Repr = u16;
    // ...
}

impl<const N: u128> IndexRepr for IndexMarker<N>
where
    ConstCheck<{ N <= u64::MAX as u128 + 1 }>: True,
    ConstCheck<{ N <= u32::MAX as u128 + 1 }>: True,
    ConstCheck<{ N <= u16::MAX as u128 + 1 }>: True,
    ConstCheck<{ N <= u8::MAX as u128 + 1 }>: True,
    ConstCheck<{ N > 0 }>: True, // Can't represent `Index<0>`, so exclude that value
{
    type Repr = u8; // Doesn't need to be `default` since it's the last item in the chain
    // ...
}

// And now the type alias:
pub type GetIndexRepr<const N: u128> = <IndexMarker<N> as IndexRepr>::Repr;

This specialization chain now correctly provides the backing type for a given Index<N>. And it even allows us to write generic versions very cleanly! We can write

impl<const N: u128> Index<N> {
    // ...
}

And there’s no need for any where clause, since the base of our specialization chain is over all N: u128. Unfortunately though - and you’ll just have to take my word for it since I’m failing to make simple reproducers - I’ve had issues with associated types in specialisation chains being opaque, or otherwise extremely annoying to work with. There have been several occasions where I would write something like

use clash_num::index::Index;

fn main() {
    let foo: Index<13> = Index::new(8u8).unwrap();
}

And then I would get an error to the effect of

error[E0308]: mismatched types
 --> src/main.rs:4:37
  |
4 |    let foo: Index<13> = Index::new(8u8).unwrap();
  |             ---------              ^^^ expected `<IndexMarker<13> as IndexRepr>::Repr`, found `u8`
  |             |
  |             expected due to this

This example (with the code above) doesn’t error, and that’s sort of the problem - such unexpected errors would crop up in the most unexpected places, and resolving them was a massive pain. Plus there’s a way to do it with one fewer nightly feature, so let’s see what that is.

Method 2: Generic const expressions🔗️

We’re instead going to use the generic_const_exprs feature in a construction I like to call a trait look-up table, or trait LUT. For this we need to do two things:

  1. Write a function that maps u128s to table keys (which will be of type u8)
  2. Change the marker type to include both the N bound as well as the table key

Let’s see what that looks like:

#![feature(generic_const_exprs)]
#![allow(incomplete_features)]

pub const fn index_size(n: u128) -> u8 {
    if n == 0 {
        panic!("Cannot represent `Index<0>`!");
    } else if n <= u8::MAX as u128 + 1 {
        8
    } else if n <= u16::MAX as u128 + 1 {
        16
    } else if n <= u32::MAX as u128 + 1 {
        32
    } else if n <= u64::MAX as u128 + 1 {
        64
    } else {
        128
    }
}

pub struct IndexMarker<const M: u128, const N: u8>;

pub trait IndexRepr {
    type Repr;

    fn bounds_check(val: &Self::Repr) -> bool;
}

impl<const N: u128> IndexRepr for IndexMarker<N, 8> {
    type Repr = u8;
    // ...
}

impl<const N: u128> IndexRepr for IndexMarker<N, 16> {
    type Repr = u16;
    // ...
}

impl<const N: u128> IndexRepr for IndexMarker<N, 32> {
    type Repr = u32;
    // ...
}

impl<const N: u128> IndexRepr for IndexMarker<N, 64> {
    type Repr = u64;
    // ...
}

impl<const N: u128> IndexRepr for IndexMarker<N, 128> {
    type Repr = u128;
    // ...
}

// And now we redefine the type alias a bit
pub type IndexLut<const N: u128> = IndexMarker<N, { index_size(N) }>;
pub type GetIndexRepr<const N: u128> = <IndexLut<N> as IndexRepr>::Repr;

Now we can write generic implementations again, except…

impl<const N: u128> Index<N>
where
    IndexLut<N>: IndexRepr, // ...it's now necessary to have this `where` clause bound.
{
    // ...
}

I haven’t had any issues like mentioned with the previous one where an associated type is suddenly less transparent than I thought it would be, which makes it generally pretty nice to work with I think. The extra where clause bound that you have to carry around for generic code is a little bit annoying, sure, but I do like the extensibility of this system.

Conclusions🔗️

Well, to begin with, we decided not to use this (for now) in Bittide since it’s relying on an incomplete nightly feature that we’re not super sure we want to use in production software at time of writing. We may use it in the future should there be a strong enough reason for us to use it over what we plan to do instead. I did still think that it was useful enough if you don’t mind opting in to that that it warranted publishing somewhere.

As for what it was like writing this - honestly, it was pretty nice once I figured out that what I should be working with is the trait LUT method rather than specialization. I plan to use this method in other things as well, since I have some other projects that use const generics to inform associated types (such as canonicalizing something that looks like heterogeneous lists). The trait LUT pattern is really great for such cases, and honestly I wish it was written down more clearly in more places, since it would’ve saved me a lot of time getting started with this project.

I’m also quite a fan of using these const fns to do the mapping, since it’s a lot easier to insert failure cases at the fn level as compared to the type level, and especially since you can much more clearly tell the user why it doesn’t work rather than just them seeing an error that a trait isn’t implemented for your type. Instead, you can take a look at the type and say exactly what’s wrong in a panic message.
